Examples

Some drawing files to help get you started

Note: For 3d-printing the drawing process is the same as laser cutting. We'll take your drawing file, render it in 3D at the thickness you order, and then print insted of cut.

12"x12" Square

This example is a drawing file for a 3" airframe laying out:

  • 3 fins
  • 2 centering rings for a 29mm motor mount

Cut lines should be in color red. All other colors will be ignored.
Download 12"x12" .dxf example file
Download 12"x12" .dxf blank template file

Responsive image

12"x18" Rectangle

This example is the same as the first one except intended for a 4" airframe.
It lays out:

  • 3 fins
  • 2 centering rings for a 38mm motor mount

Cut lines should be in color red. All other colors will be ignored.
Download 12"x18" .dxf example file
Download 12"x18" .dxf blank template file

Responsive image
